Philips HF R TD 226 42 PL C/T EII 2 x PL C/T 26/32/42W

  • Beschrijving
  • Specificaties

HF-Regulator II Touch and Dali for PL-T, PL-C and PL-R lamps

• General Characteristics
Interface TD Rated Number of Lamps 2 piece

Rated Ballast-Lamp Power 26-42
Rated Lamptype PL-T/C
Application code EII
Line Voltage 220-240 V
Line Frequency 50/60 Hz
Housing S 123x79x33
Ignition Method Warm Start
Lifetime 90%
surv.@Tcaselife 50000 hr

Energy Efficiency Index A1
• Operating Characteristics
Battery voltage
running lamps 154-276
Battery voltage lamp ignition 196 V
Control input protection Yes
Inrush current Peak 45 (max) A
Inrush current Width 0.35 ms
Max ballast on
MCB(16A type B) 12 x

Earth leakage current 0.5 (max) mA
Mains voltage safety (AC) -10%/+10%
Mains voltage performance (AC) -8%/+6%
Overvoltage protection 320Vac 48 hr
Overvoltage protection 350Vac 2 hr

Power losses gear 6.0-7.5 W
Regulating level power 1%-100%
Standby power consumption 0.35 (max) W
Ballast Lumen Factor 0.99 -
Crestfactor 1.7 (max) -
Ignition time 0.2 (max) s
Operating frequency 101 (max) kHz
Total Harmonic

Distortion EUR 10 %
Hum and Noise level Inaudible

• Temperature Characteristics
T-ignition 0 (min), 50 (max) C
T-ambient -20 (min), 50 (max) C
T-storage -20 (min), 80 (max) C
• Approval & Application Chars
EMI 9kHz .. 30 MHz EN 55015
EMI 30 MHz ..1000MHz
EN 55022 level B [Level = Class]
Safety Standard IEC 61347-2-3

Performance
Standard IEC 60929
Quality Standard ISO 9000:2000
Environmental
Standard
ISO 14001
Harmonic current emissions IEC 61000-3-2
EMC Immunity IEC 61547
Vibrations IEC 68-2-6 Fc
Bumps IEC 68-2-29 Eb
Humidity EN 61347-2-3 clause 11
Approval marks ENEC / VDE-EMV
CE marking Yes
Temperature
marking
110 [Yes]
Emergency standard IEC 60598-2-22

• Product Dimensions
Length A1 123 mm

Fixing Hole Distance
Length A2 111 mm
Width B1 79 mm
Height C1 33 mm
Fixing Hole Diameter D1 4.5 mm

• Product Data
Order code 913700625782
Full product code 913700625782
Full product name HF-R TD 2 26-42 PL-T/C EII 220-240V
Order product name HF-R TD 2 26-42 PL-T/C EII 220-240V

Pieces per pack 1
Packing configuration 12
Packs per outerbox 12
Bar code on pack -
EAN1 8711500913371

Bar code on
outerbox - EAN3 8711500913388
Logistic code(s) - 12NC 913700625782

Ordercode 91337130

SKU 100012567
Net weight per piece 0.230 kg

Aantal lampen 2
Geschik voor Wattage 26W - 42W
Intelligent (multiwattage) Ja
Dimbaar Ja, Dali
