Philips HID-PV C 50/I CDM 220-240V

  • Beschrijving
  • Meer
  • Specificaties

PHILIPS HF-P III VSA HID-PV C 50/S CDM 220-240V EAN:8711500933635

Speciaal voor 1 x 50W CDM lampen

-Voordelen Optimale lampprestaties dankzij minimale tolerantie op lampvermogen
-Levensduur CDM-lamp met tot 30% verlengd -
-Voorkomt al het zichtbare geknipper van lampen
-Minimale spreiding van lampvermogen -VSA met laag vermogensverlies
-Detectie van einde lamplevensduur
-Hoge omgevings- en behuizingstemperaturen
-Lange levensduur van 40.000 uur

General Information Lamp Type CDM
Number of Lamps 1 piece/unit
Suitable For Outdoor Use No
Number of Products on MCB (16A Type B) (Nom) 24
Automatic Restart Yes
Operating and Electrical
Input Voltage  220 to 240 V
Input Frequency 50 to 60 Hz
Operating Frequency (Nom) 0.14 kHz
Power Factor 100% Load (Nom) 0.95
Ignition Voltage (Max) 4.0 kV
Ignition Switch-Off Time (Nom) 18 min
Mains Voltage Performance (AC) -10%-+6%
Mains Voltage Safety (AC) -18%-+10%
Earth Leakage Current (Max) 0.25 mA
Inrush Current Width 0.25 ms
Constant Wattage Deviation -3%/+3%
Power Losses (Nom) 6 W
Inrush Current Peak (Max) 26 A
Wiring Cable Capacity Output Wires Mutual (Nom) 150 pF
Cable Length From Device to Lamp 2.0 m
Wire Striplength 10.0-11.0 mm
Ballast Contact Wire Cross Section 0.50-2.50 mm²
Connector Type Insert

System characteristics
Rated Ballast-Lamp Power 50 W
TemperatureT-Ambient (Max) 50 °C
T-Ambient (Min) -20 °C
T-Storage (Max) 75 °C
T-Storage (Min) -25 °C
T-Case Lifetime (Nom) 75 °C
T-Case Maximum (Max) 75 °C

Mechanical and Housing
Housing /I
Approval and Application IP Classification  20
Active Temperature Protection Yes
EMI 9 kHz ... 300 MHz
CISPR 15 ed 7.2
Safety Standard
IEC 61347-2-3
Quality Standard
ISO 9000:2000
Environmental Standard
ISO 14001
Harmonic Current Emission Standard
IEC 61000-3-2
EMC Immunity Standard
IEC 61547
Vibration Standard
IEC68-2-6 F c
Bumps Standard
IEC 68-2-29 Eb
Humidity Standard
IEC 928-13
Approval Marks
CE marking
Material Nr. (12NC) 913700665166
Net Weight (Piece)
0.360 kg

Aantal lampen: 1
Geschik voor Wattage: 50W
Dimbaar: Nee
