Osram QTP-T/E 2X26-32/220-240

  • Beschrijving
  • Filter
Te gebruiken voor: 2x DULUX D/E 26W, DULUX F 18W, DULUX F 24W, DULUX F 36W, DULUX L 18W, DULUX L 24W, DULUX L 36W, DULUX T/E 26W, DULUX T/E 26W CONSTANT, DULUX T/E 32W, DULUX T/E 32W CONSTANT, DULUX T/E 42W, DULUX T/E 42W CONSTANT, FC 22W, HO 24W, L 18W, L 18W XT, L 18W XXT.
Input voltage AC198…264 V
Line current0.30 A
Nominal voltage220…240 V
Mains frequency50…60 Hz
Input voltage DC176…276 V
Operating frequency
45 kHztrue
Max. ECG no. on circuit breaker 10 A (B)
11true
Max. ECG no. on circuit breaker 16 A (B)
19true
Inrush current25 A

LIGHT TECHNICAL DATA

Starting time1.0 s

DIMENSIONS & WEIGHT

Length123.0 mm
Width79.0 mm
Height33.0 mm
Mounting hole spacing, length111.0 mm
Product weight180.00 g
Cable cross-section, output side0.5…1.5 mm²
Cable cross-section, input side0.5…1.5 mm²

TEMPERATURES & OPERATING CONDITIONS

Ambient temperature range-20…+50 °C
Permitted rel. humidity during operation
5…85 %true

LIFESPAN

ECG lifetime
50000 h
Aantal lampen: 2
Geschik voor Wattage: 26W - 32W
Intelligent (multiwattage) Ja
Osram
4008321329158
