Product Details
Partcode: ILHBC148E
Check Code: 855584
Range Name: Tough-Shell
Product Type: Circular High Bay
Warranty: 5 Years
CE / RoHS: Yes
Physical Data
Product Finish: Matt Black
Optic: Polycarbonate diffuser
Material: Aluminium, Polycarbonate
Construction: Aluminium heat-sink, PC injection moulded driver case
Physical Data
Length: 139mm
Width: 360mm
Depth: 139mm
Diameter: 360mm
Weight (Unpackaged Single Unit): 6500g
Lamp or Luminaire Shape: Round
Luminaire Fixing: Suspended
Electrical Data
Voltage Range: 100-240V
Power Consumption: 200.0 Watts
Driver included: Yes
Electric Current: AC
Frequency Range: 50/60 Hz
Power Factor: >=0.95
Dimming: Dimmable
LVD Certified: Yes
EN: EN-60598, EN61000, EN61547, EN55015, IEC62321
Light Data
Useful Lumens: 26000lm (Rated luminous flux in a 90° cone)
Lumens: 26,000lm
Lumens per Watt: 130.0lm/W
Beam Angle: 120°
Correlated Colour Temperature (CCT): 4000k
Colour Temperature: Cool White
Colour Rendering Index (CRI): >=73
LED Type: Surface mounted device (SMD)
Instant on - Less than 1 second: Yes
Lifetime: 50,000 hrs
Switching Cycles: >25,000 X
Lowest Operating Temperature: -30 degrees
Maximum Operating Temperature: 45 degrees
IK (Impact Protection) Rating: 8
IP (Ingress Protection) Rating: IP40
Hg 0% (Mercury Free): Yes
Packaging
EAN Barcode (unit of 1): 5055788246190
Packaged Weight (Unit of 1): 8,200g
Length (unit of 1): 445mm
Width (unit of 1): 225mm
Depth (unit of 1): 445mm
