General Information
Type Version ng
Lamp Type CDM
Number of Lamps 1 piece/unit
Automatic Restart Yes
Input Voltage 220 to 240 V
Input Frequency 50 to 60 Hz
Operating Frequency (Nom) 0.14 kHz
Power Factor 100% Load (Nom) 0.95
Ignition Voltage (Max) 4.0 kV
Ignition Switch-Off Time (Nom) 18 min
Mains Voltage Performance (AC) -10%-+6%
Mains Voltage Safety (AC) -18%-+10%
Earth Leakage Current (Max) 0.25 mA
Inrush Current Width 0.25 ms
Constant Wattage Deviation -3%/+3%
Power Losses (Nom) 4.5 W
Inrush Current Peak (Max) 26 A
Wiring Cable Capacity Output Wires Mutual (Nom) 150 pF
Cable Length From Device to Lamp 2.0 m
Ballast Contact Wire Cross Section 0.50-2.50 mm²
System characteristics
Rated Ballast-Lamp Power 35 W
Temperature T-Ambient (Max) 50 °C
T-Ambient (Min) -20 °C
T-Storage (Max) 75 °C
T-Storage (Min) -25 °C
T-Case Lifetime (Nom) 75 °C
T-Case Maximum (Max) 75 °C
Mechanical and Housing Housing /I
Approval and Application
Active Temperature Protection Yes
EMI 9 kHz ... 300 MHz
CISPR 15 ed 7.2
Safety Standard
EN 61347-2-12
Quality Standard
ISO 9000:2000
Environmental Standard
ISO 14001
Harmonic Current Emission Standard
EN 61000-3-2
EMC Immunity Standard
EN 61547
Vibration Standard
IEC68-2-6 F c
Bumps Standard
IEC 68-2-29 Eb
Humidity Standard
IEC 928-13
Approval Marks
CE marking
ENEC certificate
Temperature Marking F
Hum And Noise Level 37 dB(A)
Product Data
Full product code 872790085973700
Order product name HID-PV C 35 /I CDM 220-240V 50/60Hz NG
EAN/UPC - Product 8711500881700
Order code 913700653166
Numerator - Quantity Per Pack 1
Numerator - Packs per outer box 12
Material Nr. (12NC) 913700653166
Net Weight (Piece) 0.360 kg
