OSRAM QTP8 2X36W 220-240V

OSRAM
4008321131645
4008321131645

 QUICKTRONIC 2x36W T8

Vervangings voorschakelapparaat voor enkelvoudige T8 armaturen. Te gebruiken bij OSRAM LUMILUX T5 of PHILIPS TL5 met lampvermogen 2x 36W of OSRAM LUMILUX 2x 36W

Electrical data

Input voltage AC

198…264 V

Nominal voltage

230…240 V

Mains frequency

50…60 Hz

Input voltage DC

154…276 V

Operating frequency

45…60 kHz

Max. ECG no. on circuit breaker 10 A (B)

17

Max. ECG no. on circuit breaker 16 A (B)

28

Inrush current

20 A

Light technical data

Starting time

2.0 s

Dimensions & weight

Length

423.0 mm

Width

30.0 mm

Height

30.0 mm

Mounting hole spacing, length

415.0 mm

Product weight

399.00 g

Temperatures & operating conditions

Ambient temperature range

-25…+55 °C

Permitted rel. humidity during operation

5…85 %

Lifespan

ECG lifetime

100000 h

Capabilities

Suitable for fixtures with prot. class

I / II

End of lamp life safety shutdown

EOL T.2

Certificates & standards

Approval marks – approval

VDE / VDE-EMC / ENEC 10

EEI – Energy Label

A2

Standards

Acc. to EN 61347-2-3/Acc. to EN 60929/Acc. to EN 55015:2006 + A1:2007/Acc. to EN 61000-3-2/Acc. to EN 61547

Protection class

I/II

Type of protection

IP20
